製品仕様
| ■ スペック | |
|---|---|
| DAC | AK4493SEQ x2 (Mono Mode) |
| 真空管 | Raytheon JAN6418 x2 |
| 真空管回路 | Gen3 Vacuum Tube Audio Circuit |
| ボリュームチャンネル | JRC NJW1195A 4 Channels e-volume |
| LPF | Dual Op-Amp x2 |
| FPGA | Re-clock, De-jitter, Re-shaping DOC |
| Head Amp | Parallel amplification, 4 pieces of low noise Op-Amp, 2 amplifiers in parallel |
| MCU | Snapdragon 425 |
| システム | Customized Android 8.1 |
| Lossless | DTA bypass Android SRC |
| ストレージ | TF x1 (support up to 1TB) |
| メモリ | 2GB RAM |
| バッテリー | 3.85V 4500mAh (17.3Wh) |
| ディスプレイ | 4.1" (720 x 1280) TFT、multi-point touch screen |
| Phone Out | 3.5mm (Single-Ended)、4.4mm (Balanced, Shared) |
| Line Out | 3.5mm (Single-Ended)、4.4mm (Balanced, Shared) |
| Digital Interface | USB Audio (in and out)、SPDIF Coaxial (USB-embedded) |
| USB Type-C | USB3.1 , OTG Storage, Digital Audio QC3.0 (PD2.0 not supported) |
| Dimension | 125 x 65.5 x 19.5 (mm) |
| Bundled Player | Cayin Music App |
| Physical Control | Volume knob, Power On/Off, Playback control |
| Colored LED | Playback Sampling Rate, Home, charging indicator |
| Chassis | Sandblasted CNC- machined Aluminum |
| Weight | ~204g (±10g) |
| 付属品 | □専用シリコンケース x 1 □強化ガラススクリーンプロテクター x 1 □USB Type Cケーブル(データ転送 / 充電)x 1 □クイックユーザーガイド(保証書)x 各1 |
